BeTen+ (B4-MIOT-MR BTP) Battery-Powered Device
BeTen+ is the evolution of the BeTen, our replaceable battery version of BeWhere's low-power 5G asset tracking device family. The BeTen+ maintains our existing suite of sensors and further incorporates built-in Wi-Fi and Bluetooth for indoor location. As well, it includes a supercapacitor to help manage battery life and the enclosure has been enhanced to IP69K.
Features and Benefits
-
Key features
- Networks: LTE-M1 / NB-IoT NB1/NB2
- Outdoor Location: GNSS
- Indoor Location: Wi-Fi / BLE 5.2
- IP69K Rugged and Dust / Water-proof enclosure
- Motion tracking, triggering updates
- Tampering detection: Alerts for unauthorized movement or tampering
- Tilt detection: For Rotation counting applications
- Configurable reporting and alerting
- On-board sensors
- Temperature
- Humidity
- Pressure
- Light
- Accelerometer
-
Benefits
- Easy to install
- Ultra-low power platform
- Low device cost
- Low deployment cost
- No reader needed
- Full coverage (deep indoor and rural areas)
- Indoor location via Wi-Fi BSSID technology
- Full coverage (available on 4G & 5G networks)
Technical Specifications
| General | |
|---|---|
| Communication | LTE CAT M1 / CAT NB1/NB2 |
| Battery | Built-in non-rechargeable Lithium Thionyl Chloride battery pack of 2AA (Li/SOCl2 3.6 V, 2x3200 mAh), with assisted Supercap 2.5F 5V. Normal Operating Voltage 3.5 – 3.65V. Under optimal LTE and GPS conditions it can produce up to 3700 events*. |
| Operating Bands | Multi Region Cat M1 /NB1/NB2 M1: LTE-FDD: B2/B3/B4/B5/B8/B12/B20/B28 NB1/NB2: LTE-FDD: B2/B3/B4/B5/B8/B12/B20/B28 North America & Europe: Cat M1 Australia: Cat M1 Brazil: NB1/NB2 |
| Data | LTE CAT M1 Packet Data (CoAP/UDP) / CAT NB1/NB2 Packet Data CoAP/LwM2M/UDP |
| SIM | 4FF (nano SIM) |
| Location | |
| GPS Receiver | High accuracy Gen9 VT of Qualcomm (GPS, GLONASS, BeiDou, Galileo and QZSS). Tracking & Navigation: –157 dBm Cold start: –146 dBm Hot start: –157 dBm Accuracy: Position accuracy <3 m CEP-50 |
| Wi-Fi Receiver | For Micro-location purpose only. Frequency: 2.4 GHz to 2.4835 GHz, Sensitivity: -70 dBm |
| Sensors | |
| Sensor | Temperature: [-40, +85]; Absolute accuracy ±0.5 °C Humidity: Absolute accuracy ±3 %RH Pressure: [300...1100 hPa], Absolute accuracy ±1 hPa |
| 3-Axis Accelerometer | Motion, Rotation |
| Light | Tamper |
| Environmental | Storage Temperature: -40 °C to +85 °C Operating Temperature: -40 °C to +75 °C (batteries, extended 75 ℃- 80 ℃ for max 4 hrs) Humidity: 95% R.H. @ 50℃ non-condensing SAE J1455: Powered Thermal Cycle, Temperature Shock Resistance, Humidity-Temperature Cycle |
| Physical | Dimensions: 107mm x 64mm x 32.5mm Weight: 0.35 lb |
| Compliance | FCC, ISED, PTCRB, CE, RCM (Australia) USA: AT&T (NO+FirstNet), FirstNet, T-Mobile, Verizon Canada: Bell, Telus, Rogers Brazil: TIM* |
